“Long story short- ALLY Machine was born in the job shops of Washington state. It’s a product of all the spindles we’ve rode, components we’ve had a hand in delivering, and a way to pay homage to the invaluable mentors Russell and I have had. Between the 2 of us we have over 20 years experience in manufacturing. all the way from, Receiving the drawing, planning, purchasing, producing, and keeping an eye on the quality.
We’ve seen firsthand the urgency needed to meet those deadlines and creativity to pull it off. We are no strangers to the 24 hour shifts or burning the candle from both ends 7 days a week to get a product over the finish line. With our passion for creating, reverse engineering, conceptualizing tooling, and continuous improvement, we are setting out to help our customers meet or exceed their on-time deliveries.
At the core of ALLY Machine, is humility, honesty, and continuous improvement. As a customer we will be extending those values to you and then some. We can offer all types of assistance, from consulting and innovating, to quality and machine optimization. Our support doesn’t stop at the door. ”
-Sam Swetland
Assistance and Support
-High Precision
-High Volume
-R&D Prototyping
-Consulting, QMS Systems, Spindle Optimization, Tooling applications.
CAPABILITIES
CITIZEN A20 SWISS LATHE
- Max Turning Diameter: 3/4”
- Min Turning Diameter: 3/16”
-5 HP Main Spindle, 2 HP Sub Spindle, 1 HP Live Tooling
- 8000 Max Main/Sub Spindle RPM, 6000 Max Live Tooling RPM
-7 Axis
- 21 Tool Stations, 5 Turning, 4 Live Cross, 4 Front Working and 8 Back working.
- Live Cross Tooling eliminates secondary operations and work holding.
-High Volume Accessories: Work Piece Conveyor, High Pressure Coolant, 12 ft Bar Loader, Chip Conveyor, and Fire Trace.
- Long Workpiece adapter.
“With a bed 1.8 times as heavy as those of existing machines, the A20 is constructed to counter thermal displacement. The relatively small thermal displacement of the bed during long periods of operation promotes high accuracy.”
DOOSAN V400 VERTICAL TURNING LATHE
-Max Turning Dia: 19.5”
-Max Turning Length: 18.1”
-30 HP
-3000 Max RPM
-12 Station Turret
“Utilizing a cartridge style spindle and a tightly coupled bearing assembly, the PUMA V centers are expertly adept at handling heavy workpieces and controlling thermal stability in long run operations. Featuring a cast iron meehanite bed and box type column casting, these machines remain stable even under the most intense cutting conditions.”
HAAS ST-20Y
Maximum Part Swing:
21.0"
Bar Capacity, Maximum Spindle Speed
2.5", 4000-rpm
Maximum Power Rating, Drive System
20 hp, Belt Drive
Spindle Nose, Chuck Size
A2-6, 8.3"
Maximum Cutting Diameter (with BOT turret)
13"
Maximum Cutting Diameter (with BMT65 turret)
11.75"
Maximum Cutting Length (varies with workholding)
22.5"
Axis Travels (X, Z)
8.4", 22.5"
Y-Axis Travel
4.0"
“The redesigned ST-20/Y has a 2.5" (63.5 mm) drawtube bore. It is 25% larger than its predecessor for increased bar capacity. The included chuck also has a larger throat to accommodate larger parts within the chuck jaws, or for greater clearance when boring or threading large holes.”
